A.O. Smith Century ST1102 Full Rated 1 HP 3.450 RPM Single Speed Pool Pump Motor
$68.54
11
People watching this product now!
Description
When your old pool pump motor calls it quits. have a replacement A.O. Smith 1-HP 3.450 RPM 56J Single-Speed Pool Pump Motor ready to swap in so you can get back enjoying your relaxing day on the water. This 1-horsepower full-rated replacement motor for above and in-ground swimming pool pumps has a threaded shaft and fits most pumps that require a 56J frame round-flange motor. It operates on both 115 and 230-volts and has a 3.450 RPM. The motor features a 1.5 service factor. an automatic surge protector. capacitor start. and an open drip-proof housing for cooler operation. The ST1102 pool pump motor is compatible with pump series models like Hayward Super II Energy Efficient. Hayward Northstar Full Rate. and Jacuzzi Magnum. A.O. Smith Century offers the very best in US-manufactured electric motors. With a comprehensive line of electric motors for commercial. industrial. and residential pump and general-purpose applications. century is a highly recognized brand in the leisure water industry for its breadth of product offering. quality. and reliability.
- Full-rated 1-horsepower 3.450 RPM 56J round-flange replacement pool pump motor
- For use with above-ground and in-ground swimming pools
- Part Number: ST1102
- 115/230-volt power; open drip-proof housing ensures cooler operation and extends the life of your motor
- Compatible pumps include: Hayward Super II Energy Efficient. Hayward Northstar Full Rate. and Jacuzzi Magnum Full Rate series
- Not California Title 20 Compliant
- Specifications:
- Product type: Pool pump motor
- Service factor: 1.5
- Voltage: 115/230 volts
- Horsepower: 1 HP
- RPM: 3.450
- Amperage: 18.6/9.3 amps
- Hertz: 60
- Surge protector: Automatic
- Ambient temperature: 122 degrees Fahrenheit
- Start type: Capacitor
- Insulation: Class B
- Motor phase: Single-speed
- Rotation: CCW pump end
- Bearing type: Sealed ball bearings
- Max load: 115-volt: 18.6 amps; 230-volt: 9.3 amps
- Flange type: Round
- Shaft type: Threaded 303 stainless steel
- Motor frame size: 56J
- Motor housing: Open drip-proof
- Pool type: Above-ground. in-ground
- Material: Stainless steel
- Color: Black
- Dimensions (L x W x H): 14 x 6.5 x 6.5 inches
- Weight: 32 pounds
- Manufacturer warranty: 1-year warranty
Specifications
| Features | enclosure: open dripproof. shaft length: 2-1/2. hz: 60. nema/iec frame: 56j. rpm range: 3001-3600. voltage: 115/230. mounting: face. nameplate rpm: 3450. item: pool and spa pump motor. bearings: ball. phase: 1. flange material: aluminum. shaft material: 303 stainless steel. hp: 1. service factor: 1.50. motor type: capacitor-start. insulation class: b. efficiency group: standard. rotation: ccw. thermal protection: auto. full load amps: 18.6/9.3. finish: black |
| Brand | A. O. Smith |
| Manufacturer Part Number | ST1102 |
| Assembled Product Dimensions (L x W x H) | 19.00 x 9.50 x 9.50 Inches |
